Model No.: FF252A2S-12G
Knitting Product Type: Sweater
Knitting Style: Flat
Knitting Method: Double
Needle Style: Compound Needle
Needle Bar Style: Flatbed Knitting Machine
Certification: ISO9001: 2000
Packaging: Wooden Case
Productivity: 1500 Sets/Month
Place of Origin: China
HS Code: 84472020
Computerized Flat Knitting Machine For Sweater
1. Colour changing system：2*8 groups of yarn mouth configurations are equipped in two sides of four guide rails for the purpose of shifting the yarn mouth at any position of needle bed( standard configuration 2*8) ；
2. The high-quanlity batching roller system, the soft upper roller traction which is specially designed, can ensure the posotion closes to the mouth of needle plate and improve the high quality batching control on the fabrics；
3. The humanity developped function of double racking within 1 line. it improved 50% effiency after adopt this function;
4. New type sinker control technology is not need manual adjustment . It greatly reduced the floating when yarn take down . The advantages is unique for without traction knitwear.
5. A2S type first use the 4.8inch compound needle-bed rail carriage, each carriage system width narrow by 30mm, to match the 0.05ms high speed return of carriage servo ( such as: for three system machine running with 90 speed, 10 lines save 1 second.) It is a leap on the basis of A2 type machine;
6. The integrated installation of sinker and cam plate of carriage, it ensure the consistency and stability between sinker device and whole carriage, and it is easier for operator to observe the looping process;
7. Add tight knitting function、expand the knitwear design varieties;
8. In the carriage, heavy use the intelligent encoder on the basis of motorized. It can find the zero position intelligently and feedback the position information circularly (it mean when send a command,it will go to finish the command and feedback the result ). It improved the qualification rate of knitwear greatly, customers and maintance staff can use it conveniently;
9. For stitch control, it use the customized motor to accurate it to 0.005mm, it greatly improve the flatness of knitwear ;
10. The raising cam is controlled seperately, can do pre-select in the middle. The carriage can turn back from the middle when automatic locking, it greatly improved the working efficiency；
Computerized Flat Knitting Machine For Sweater is able to knit the basic knitting organizations (full needle,single side etc), multicolour random jacquard weave, applique(intarsia), twist knitting, pointelle and other weft knitting organizations. It is applicable for real silk, spun silk, synthetic, wool, acrylic, blended, yarn and other raw materials toknit the sweater and scarf, cap, trousers,socks and garment accessories.
Knitting system: single head double system,single head three system
Gauge: 12G, 14G，16G
Knitting range: 36, 40, 48, 52, 56, 60, 72Inch
Knitting speed: it adopts 24 segments with the maximum speed of 1.5m/s. AC servo motor control is adopted and controlled by refined feedback control and DSP with high-speed computation capability, for the purpose of controlling the IGBT to generate precise current output.
Needle bed shifting: AC servo motor control is adopted with the needle shifting range realizing 2 inches; in the meantime, it is of precise fine tuning functions.
Yarn feed device: Positive yarn feeder and guide wheel with standard configuration has greatly reduced the resistance of yarn feeding.
Power: single phase 220V/three phase 380V; it adopts the advanced CMOS technology to memorize and recover at the moment of power cut.
