Model No.: FF256A2R-7G
Knitting Product Type: Sweater
Knitting Style: Flat
Knitting Method: Double
Needle Style: Compound Needle
Needle Bar Style: Flatbed Knitting Machine
Certification: ISO9001: 2000
Packaging: Wooden Case
Productivity: 1500 Sets/Month
Place of Origin: China
HS Code: 84472020
Computerized Flat Knitting Machine For Sweater
This is computerized flat knitting machine with single carriage double system. This series is economictype.flat knitting machine applies digital technology to achieve tranfers,tuck,eyelet stitch,jacquard,apparent shape,hidden shape and other regular pattern knitting functions.
Flat knitting machine can knit basic stitch like plain stitch, rib fabric, links and links, interlock stitch, etc. irregular multicolor jacquard, twit flowers weft organization, aran, cord weave, racked stitch, cable, etc.flat knitting machine is suitable to use synthetic, wool, acrylic, mixed fiber, yarn material etc to knit readymade cardigan, hat, scarf and accessories of cloth.
1. Carriage turn back with high speed（maximum to 0.05ms), optimized the turning distance；
2. All controlled by motor, cancel the magnet, that achieved precise control；
3. The high speed motor controlled varied stitch, within 4mm carriage running zone can finished 1mm varied stitch value ! Greatly reflect the varied stitch application；
4. The raising cam is controlled seperately, can do pre-select in the middle. The carriage can turn back from the middle when automatic locking, it greatly improved the working efficiency；
5. Colour changing system：2*8 groups of yarn mouth configurations are equipped in two sides of four guide rails for the purpose of shifting the yarn mouth at any position of needle bed( standard configuration 2*8) ；
6. The high-quanlity batching roller system, the soft upper roller traction which is specially designed, can ensure the posotion closes to the mouth of needle plate and improve the high quality batching control on the fabrics；
7. New type sinker control technology is not need manual adjustment . It greatly reduced the floating when yarn take down and reduced missed stitch when do transfer, thus the qualification rate has improved greatly.
three phase 380V; it adopts the advanced CMOS technology to memorize and recover at the moment of power cut.
Computerized Flat Knitting Machine For Sweater is able to knit the basic knitting organizations (full needle,single side etc), multicolour random jacquard weave, applique(intarsia), twist knitting, pointelle and other weft knitting organizations. It is applicable for real silk, spun silk, synthetic, wool, acrylic, blended, yarn and other raw materials toknit the sweater and scarf, cap, trousers,socks and garment accessories.
Knitting system single head double system,single head three system
Gauge 2.5G, 3G, 3.5G, 5G, 7/5G, 6/5G, 6/7G, 7G, 8G, 9G, 10G, 12G, 14G
Knitting range 36,44,48,52,56,60,72Inch
Knitting speed It adopts 24 segments with the maximum velocity of 1.2m/s. AC servo motor control is adopted and controlled by refined feedback control and DSP with high-speed computation capability, for the purpose of controlling the IGBT to generate precise current output.
Needle bed shifting AC servo motor control is adopted with the needle shifting range realizing 2 inches; in the meantime, it is of precise fine tuning functions.
Yarn feed device Positive yarn feeder and guide wheel with standard configuration has greatly reduced the resistance of yarn feeding.
Power single phase 220V/three phase 380V; it adopts the advanced CMOS technology to memorize and recover at the moment of power cut.
